MLT980MA adopts 8.4 "color LCD, new appearance design, horizontal,
vertical two structural forms. Maximum control 5 axes (including
C-axis), minimum instruction unit 0.1 μm. Has online CAM function, chart
programming, hand pulse Test and other functions, high-speed drilling,
rigid tapping, cylindrical interpolation and other functions, support
discs of discs, bucket knives and knife knives. Its interface is fully
compatible with MLT980MDC, functional configuration The adaptation of
the absolute and incremental servo device is supported by MLT980MA,
which is the choice of the popularity of the number-controlled milling
machine and the machining center machine!
Main technical features 8.4 "Color LCD, new appearance design has
high-speed drilling, rigid tapping, milling, milling level, etc.,
processing control support discs, bucket type knife library, adaptive
support screw Milling and machining features online CAM, chart
programming, contour programming and other functions, programming simple
hand test, MDI multi-segment operation, ladder online monitoring,
debugging efficient free adaptation absolute, incremental servo drive
Technical specifications
|
Item
|
MLT980Ma
|
|
LCD
|
8.4LCD
|
|
Control axis
|
maximum control axes: 5 axis
|
|
Linkage axes: 5 axis (straight), 3 axis (spiral)
|
|
Position command
|
Minimum instruction unit: 0.0001mm
|
|
xx快速移动速度：60000 mm/min
|
|
xx切削进给速度：30000 mm/min
|
|
Directive range: ± 99999999 × minimum instruction unit
|
|
Adapted to beware type
|
Disc type, bucket type, row
|
|
DXF file recognition
|
stand by
|
|
Proportional zoom
|
Have
|
|
Coordinate rotation
|
Have
|
|
Mirror
|
Have
|
|
Hand shaker
|
not support
|
|
Machine I / O
|
41 point input / 37 point output
|
|
Additional panel I / O
|
16-point input / 8 point output
|
|
Dimensions
|
420 ×
260 × 80 (width × height × deep, unit: mm)
|
|
Adaptive servo
|
can be adapted to adapt the
absolute or incremental servo drive
|
