    MLT-CK5112E

    -+
    Q&A Buy It Now Focuses on
    Pay attention to the public number, menu purchase wholesale
    View count : Likenum int: Comment : Sold:



    规格参数

    加工能力  Processing specification
    车削直径上限  Max cutting workpiece diameter 1200 mm
    工作台直径 Workbench diameter 1010 mm
    工件高度 上限  Max workpiece height 1000 mm
    工件重量 上限  Max workpiece weight 5000kg
    工作台扭矩上限  Max torque of workbench 12.5 kN.m
    工作台转速级数  Circular speed grade of workbench Ⅱ档 无级 Stepless
    工作台转速范围  Circular speed range of workbench 1~200 r/min
    垂直切削力上限  Max. vertical cutting force 20 kN
    刀架进给量级数  Cutter frame feeding grade 无级 Stepless
    刀架进给量范围  Cutter frame feeding range 0.2~500 mm/min
    垂直刀架滑枕垂直行程  Vertical cutter frame vertical travel 650 mm
    垂直刀架水平行程  Vertical cutter frame horizontal travel  -20~700 mm
    刀架快速移动速度  Cutter frame moving speed 2000 mm/min
    横梁行程  Beam moving range 760 mm
    滑枕尺寸  Ram size 190×300 mm(T型滑枕)
    刀杆截面高度上限  Max height of cutter bar cross section 40 mm
    主电机功率  Main motor power 22kW
    横梁升降电机功率  Beam lifting motor power 2.2 kW
    数控系统  NC system MLT-T208V
    基本尺寸及重量  Size and weight
    主机尺寸  Floor space   (长L ×宽W ×高H )  3485×2570×4300 mm
    主机重量  Host weight 10100kg
